Utility Relief | Kunkle Valve
Extra-heavy rugged construction non-code bronze liquid relief valves with a variety of model options to meet specific applications
A range of valves suitable for overpressure relief and protection of pumps, tanks, lines and hydraulic systems; pressure regulation and continuous by-pass relief.
Steam Safety Direct Spring | Kunkle Valve
Non-code steam service sentinel relief valves
Models 40R and 40RL are suitable for sentinel (warning) on steam equipment, including steam turbines. They are intended as audible warning devices, not for pressure relief.
Utility Relief | Kunkle Valve
Extra heavy, rugged construction non-code liquid relief valves with a variety of model options to meet specific applications
Suitable for overpressure relief, pressure regulation, by-pass relief and protection of pumps, tanks, lines and hydraulic systems containing acid, caustic, ammonia and other corrosive liquids requiring iron, steel or SS materials.
Utility Relief | Kunkle Valve
Cast iron liquid relief valves with bronze trim including models UL and FM approved for fire pump installations
Liquid relief valves suitable for overpressure relief, pressure regulation and protection of pumps, tanks, lines and hydraulic systems. Models 218, 228 are UL 1478 listed and FM approved for fire pump service.
Utility Relief | Kunkle Valve
Stainless steel liquid relief valve with a side outlet suitable for a variety of applications up to 300 psig (20.7 barg)
Model 140 is a general utility valve of all stainless steel construction, including spring, for non-code liquid applications.
Utility Relief | Kunkle Valve
Cast iron non-code vacuum relief and ASME Section VIII air/gas, ‘UV’, National Board certified safety valves, both PED certified for non-hazardous gas
Model 215V is suitable for the protection of high volume vacuum pumps, conveying systems and light gauge tanks. Model 337 for the protection of low to medium pressure high volume blowers, compressors, conveying systems and bulk hauling trailers/equipment.
Utility Relief | Kunkle Valve
Safety and relief valves for non-code liquid relief that meet ASME Section VIII for air/gas and steam and are National Board certified
These valves are suitable for the protection of pumps, compressors, pressure vessels or systems handling corrosive fluids or vapors at high pressure and/or temperature. Also for sentinel (warning) services on steam equipment.
Steam Safety Direct Spring | Kunkle Valve
Cast steel, exposed spring valves that meet ASME section I for steam and ASME section VIII for air, gas and steam services
Suitable for use on steam boilers and generators, pressure reducing stations, reciprocating or rotary air/gas compressors and for pressure vessels including tanks, receivers, intercoolers, oil/gas separators and lines.
Steam Safety Direct Spring | Kunkle Valve
A safety relief valve that meet ASME section IV, ‘HV’, for low pressure hot water boilers and is National Board certified.
These valves serve the dual purpose of relieving overpressure created by thermal expansion under normal firing conditions and overpressure in the form of water or steam created in over-firing due to failure of electrical or other controls on hot water boilers, heat exchangers and generators.
Utility Relief | Kunkle Valve
Brass or stainless steel safety valves with a choice of Buna-N (NBR), Viton® (FKM) or stainless steel seats that meet ASME section VIII, ‘UV’, for air/gas and are National Board certified
Suitable for use on small to medium size single and multi-stage air compressors, intercoolers, aftercoolers, instrument/control air lines and systems. Also for air tanks/receivers and pressurized equipment.
Utility Relief | Kunkle Valve
Bronze, steel and stainless steel safety relief valves for air, gas, steam, liquid and vacuum service that meet ASME Section VIII, ‘UV’; Section I, ‘V’, are National Board certified and PED certified for non-hazardous gas
Suitable for air/gas compressors, liquid filled pressure vessels/systems, high temperature/pressure hot water boilers, for pressure vessels containing air, gas or steam and process and industrial applications requiring steel/stainless steel construction. Also for vacuum service.
Utility Relief | Kunkle Valve
High capacity cast iron safety valve that meets ASME section IV steam standard ‘HV’ and is National Board certified
Model 930 is suitable for use on low pressure steam heating boilers to ASME code section IV at 15 psig set pressure.
Utility Relief | Kunkle Valve
Bronze safety valves to ASME section I and VIII, steam, ‘V’ and ‘UV’; section VIII, air/gas, ‘UV’ National Board certified including models to ASME section IV, steam ‘HV’. PED certified for non-hazardous gas
These valves are suitable for use on steam boilers and generators, reciprocating or rotary, portable or stationary air/gas compressors, intercoolers and aftercoolers. Also for pressure vessels containing steam, air or non-hazardous gas and on pressure reducing stations.
Steam Safety Direct Spring | Kunkle Valve
Cast iron ASME section I steam and section VIII, air, steam and gas ‘UV’ National Board certified safety valves including model 6254 to ASME section IV ‘HV’, PED certified for non-hazardous gas
Suitable for use on steam boilers and generators, pressure reducing stations, reciprocating or rotary air/gas compressors and for pressure vessels including tanks, receivers, intercoolers, oil/gas separators and lines.
Cv Techserv, Inc. . Copyright 2017
2631 Industrial Court, Hastings, MN 55033 . 651.438.2500
Brought to you by M-Vision Web Design
Our Products
We offer Kunkle pressure relief valves in ½” through 6” sizes suitable for set pressures to maximum 800 psig steam, vacuum to 3000 psig air, and 3300 psig liquid.
Our inventory of over 1600 valves and 3000 loose springs allows us to meet your customers’ design and set point requirements while satisfying rapid delivery requests. If you need additional help, contact us.
Below are links to Technical Specifications and documentation for each of the various models we normally carry in our inventory.
